• Weight: Aprox 280 g (0.62 lb.)
• Color: White
• Material: Aluminum alloy material with surface spray treatment
• Dimension: Ø 137 mm × 42 mm (Ø 5.4″ × 1.7″)
• Waterproof design
• Side outlet and bottom outlet
• Interchangeable bottom waterproof cover, and side gland nut

Compatible with:

Hikvision Cameras: 4MP DS-2CD2346, DS-2CD2347 Series, 8MP DS-2CD2386, DS-2CD2387 Series

Hilook: 6MP IP ColorVU Dual Lens IPC-T260HAD, 8MP IP ColorVU Dual Lens IPC-T280HAD

Hizone Pro: 3K TVI Smart Hybrid ColorVU Dual Lens (T559W)

Notes

• The junction box should be installed on the flat surface
• Waterproof rubber is necessary for outdoor application
• The wall must be capable of supporting at least 3 times as much as the total weight of the camera and the mounting bracket
• The maximum load capacity of the junction box is 4.5 kg (9.9 lb.)
